AUDIO ACE WILD 12" V3 DUAL 4 OHM SUBWOOFER
Product Overview: The Reborn Crowd Favorite 12-Inch Driver
The Audio Ace Wild V3 12" D4 is the revived crowd-favorite model, perfectly positioned between the Joker and Jester subwoofers to offer an excellent blend of power, reliability, and sound quality. Conservatively rated at a stout 2,000W RMS, the Wild features a large 252 Oz motor, a durable ribbed surround, a heavy-duty bolted spider ring, and a high-temperature 3-inch voice coil. The Dual 4 Ohm impedance provides flexible wiring for a 2 Ohm or 8 Ohm final load. This 12-inch subwoofer is highly versatile, being Sealed, Ported, 4th order, and 6th order friendly.
| AUDIO ACE WILD 12" DUAL 4 OHM SPECIFICATIONS | |
|---|---|
| Model | Wild 12" |
| RMS Power Handling (Conservative) | 2,000 Watts |
| Nominal Impedance | Dual 4 Ohm (D4) |
| Voice Coil | 3" High Temp Coil |
| Motor Weight | 252 Oz |
| Basket | Tried and True 6 Spoke |
| Cutout Diameter | 11.181 inches |
| LOSS FACTORS & MISC PARAMETERS | |
| Total Q (Qts) | 0.497 |
| Mechanical Q (Qms) | 4.696 |
| Electrical Q (Qes) | 0.556 |
| Free Air Resonance (Fs) | 34.6 Hz |
| Sensitivity (Lm) | 83.52 dB |
| Equivalent Volume (Vas) | 18.9781 L |
| Moving Mass (Mms) | 412.248 g |
| BL Factor (Bl) | 32.279 |
| DC Resistance (Re) | 6.47 Ohms |
| Effective Piston Area (Sd) | 510.71 |
Original: $379.00
-65%$379.00
$132.65Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Product Overview: The Reborn Crowd Favorite 12-Inch Driver
The Audio Ace Wild V3 12" D4 is the revived crowd-favorite model, perfectly positioned between the Joker and Jester subwoofers to offer an excellent blend of power, reliability, and sound quality. Conservatively rated at a stout 2,000W RMS, the Wild features a large 252 Oz motor, a durable ribbed surround, a heavy-duty bolted spider ring, and a high-temperature 3-inch voice coil. The Dual 4 Ohm impedance provides flexible wiring for a 2 Ohm or 8 Ohm final load. This 12-inch subwoofer is highly versatile, being Sealed, Ported, 4th order, and 6th order friendly.
| AUDIO ACE WILD 12" DUAL 4 OHM SPECIFICATIONS | |
|---|---|
| Model | Wild 12" |
| RMS Power Handling (Conservative) | 2,000 Watts |
| Nominal Impedance | Dual 4 Ohm (D4) |
| Voice Coil | 3" High Temp Coil |
| Motor Weight | 252 Oz |
| Basket | Tried and True 6 Spoke |
| Cutout Diameter | 11.181 inches |
| LOSS FACTORS & MISC PARAMETERS | |
| Total Q (Qts) | 0.497 |
| Mechanical Q (Qms) | 4.696 |
| Electrical Q (Qes) | 0.556 |
| Free Air Resonance (Fs) | 34.6 Hz |
| Sensitivity (Lm) | 83.52 dB |
| Equivalent Volume (Vas) | 18.9781 L |
| Moving Mass (Mms) | 412.248 g |
| BL Factor (Bl) | 32.279 |
| DC Resistance (Re) | 6.47 Ohms |
| Effective Piston Area (Sd) | 510.71 |
